BR 1050

Mobile crushing and recycling plant Model BR 1050 with jaw crusher 1050 x 700 mm on crawler-chassis for the crushing of building debris, concrete (with or without reinforcement) and natural stone.

Main Components
Feed hopper with a volume of approx. 10 cbm
Vibrating feeder 1,180 x 4,800 mm with a step grate for pre-screening on the discharge side
Conveyor, belt size 800 x 3,500 for pre-screen material
Single-toggle jaw crusher 1,050 x 700 mm; gap width between 40 and 160 mm; performance approx. 50 to 180 cbm/h
Vibrating feeder 1,200 x 2,500 mm
Discharge conveyor, size 1,000 x 9,500 mm
Power unit: 190 kW/1,500 RPM (approx.) with 75 kVA Generator
Crawler-chassis; track shoe width 500 mm; axle base approx. 3,790 mm
Control unit
Options: magnetic separator; speed control for vibrating feeder; radio remote control
Transport dimensions: width 3,000 mm; length 17,420 mm; height 4,000 mm; weight approx. 54,000 kg
